三工位钟罩炉结构特点：

1、 西格马钟罩炉采用陶瓷纤维作为炉膛材料、具有重量轻保温效果好、节能等特点。

2、 升温速度快、空炉升温时间为30-90分钟。

3、 可设计方形或圆形炉膛可采用于五面加热或六面加热技术。

4、 可设计采用炉内空气微循环技术温度均匀性达±6℃

5、 可选择手动液压升降或电动液压升降技术。

6、 设计活动转轮使底座移动方便、便于装卸。

7、 中文菜单操作界面简单、易懂、无低记录历史数据和升温曲线、10段以上可编程控制、可随时设计6组工艺路线、供随时调用、PIP参数自整理功能、整理好的PIP参数可储存。

8、 可通过RS232通用接口与PC机相连接、采用SGM9900专用数据管理软件、可记录、通讯、打印历史数据和历史曲线。

9、 西格马可设计1100℃、1200℃、1400℃和1600℃高温钟炉、1600℃以上高温钟罩采用新X型双炉膛结构、具有高温不塌陷不掉灰的特点。

Structure features of three position bell jar furnace:

1. Sigma bell jar furnace uses ceramic fiber as furnace material, which has the advantages of light weight, good heat preservation effect and energy saving.

2. The heating speed is fast, and the heating time of the empty furnace is 30-90 minutes.

3. Square or round furnace can be designed, which can be used in five side heating or six side heating technology.

4. The temperature uniformity of air microcirculation technology in the furnace can be designed to reach ± 6 ℃

5. You can choose manual hydraulic lifting or electric hydraulic lifting technology.

6. The movable runner is designed to make the base move easily and convenient for loading and unloading.

7. The operation interface of Chinese menu is simple, easy to understand, without low record historical data and temperature rise curve, programmable control for more than 10 sections, 6 groups of process routes can be designed at any time, available for call at any time, self-organizing function of PIP parameters, and sorted PIP parameters can be stored.

8. It can connect with PC through RS232 general interface, use sgm9900 special data management software, record, communicate, print historical data and curve.

9. Sigmar designed the high temperature bell furnace at 1000 ℃, 1200 ℃, 1300 ℃, 1600 ℃ and 1700 ℃, and the bell cover above 1600 ℃ adopts the new X-type double furnace structure, which has the characteristics of high temperature without collapse and ash falling.

什么是钟罩炉？
采用炉体升降的高温烧结炉命名为钟罩炉，适用于被烧结物在移动时容易损坏的烧结试验。
